Mesh top for shelving

ART.	W (mm)	D (mm)	H (mm)	Scope (kg)	Wire diameter (mm)
DS-PG-890x810	890	810	40	1000	4.3
DS-PG-890x910	890	910	40	1100	5
DS-PG-890x1010	890	1010	40	1000	5
DS-PG-1115x1010	1115	1010	40	1500	5
DS-PG-1320x1010R	1320	1010	40	1500	5
DS-PG-1460x1010	1460	1010	40	1300	5
DS-PG-1320x1110R	1320	1110	40	1500	5
DS-PG-890x1110	890	1110	40	1000	5
DS-PG-890x1210	890	1210	40	900	5
DS-PG-890x10104	890	1010	40	600	4

W=Width
D=Depth
H=Height
The measurements are expressed in millimetres

Download technical data sheet

General informations

The Grid Plan mesh shelves are valid panels with reinforcing omegas that allow a resistant alternative to wood and blind loading floors.
Ready for assembly and at a competitive cost, they are a guarantee for the correct functioning of fire sprinkler systems.
Standard availability for shelves in a depth of 1000 mm, with lengths adaptable to any beam length.
The following variant with a length (L) of 890 mm is available upon request:

• 800mm deep
• 900 mm of depth
• 1100 mm of depth

For further information, please consult the technical data sheet
