Upper section with sliding doors for wardrobe - 1 mobile shelf - rounded edges
Have any questions? Request assistance
| ART. | L (mm) | P (mm) | H (mm) | No. of shelves | Weight (kg) |
| 212590 | 1200 | 375 | 900 | 1 | 37 |
| 212090 | 1200 | 450 | 900 | 1 | 40 |
| 212690 | 1200 | 600 | 900 | 1 | 50 |
| 215590 | 1500 |
375 |
900 | 2 | 45 |
| 215090 | 1500 | 450 | 900 | 2 | 49 |
| 215690 | 1500 | 600 | 900 | 2 | 55 |
| 218590 | 1800 | 375 | 900 | 2 | 52 |
| 218090 | 1800 | 450 | 900 | 2 | 57 |
| 218690 | 1800 | 600 | 900 | 2 | 64 |
| 220590 | 2000 | 375 | 900 | 2 | 35 |
| 220090 | 2000 | 450 | 900 | 2 | 63 |
| 220690 | 2000 | 600 | 900 | 2 | 68 |
L=Width
P=Depth
H=Height
The measurements are expressed in millimetres
General information
The open top unit is the completion of wardrobes with sliding doors (or, if desired, also versions with hinged doors, open doors, tempered glass doors and metal mesh doors, of compatible dimensions) and which allows them to be raised by 900 mm.
- Steel sheet painted with scratch-resistant epoxy powders.
- Rounded edges.
- Sliding doors.
- One or two shelves designed for the application of suspended files at 330 mm intervals.
- Available colours: Grey (RAL 7035), Anthracite (RAL 7016), Sand (RAL 1013), Metallic (RAL 9006), White (RAL 9010) and Black (RAL 9005).
- Additional colors beyond those selectable are available upon request only .
Made of DCO1 steel sheet (formerly FeP01, ref. EN 10130 91 + A1-98 standards) with thicknesses of 8 tenths, with assembly details in 15 tenths.
The sides of the cabinets, with a rounded front external edge with a radius of 6mm, are fixed to the base using 4+4 metal hooks stamped in 15/10 sheet metal, the top is fixed to the sides using 4 8MA threaded bolts.
The backs are fixed to the cabinet structure with self-tapping screws, to ensure maximum rigidity.
They feature sliding doors with ball bearings on special metal tracks, recessed handles and Yale-type lock.
NB It is advisable to always check that the dimensions are correct with respect to the base cabinet above which you intend to position the riser.
Upon request, they are also available with a wooden shelf that allows them to be used on the floor as low-height wardrobes or bookcases.
The anti-scratch epoxy powder coating is carried out after a microphosphating process with passivating neutralization. Drying takes place in a thermal tunnel with heat progression (180°) and at a controlled temperature.
The metal cabinets have been designed and tested according to the following UNI standards:
UNI 8596/84 Stability
UNI 8597/84 Structural resistance
UNI 8601/84 Bending of planes
UNI 8603/84 Resistance of the floor supports
UNI 8602/84 Opening and closing of doors with impact
UNI 8600/84 Bending with concentrated load
UNI 8607/84 Durability of doors
UNI 8606/84 Maximum total load
Finishing tests:
UNI ISO9227/93 Corrosion resistance
UNI 9427/89 Resistance to light
UNI 8901/86 Impact resistance
UNI 115/87 Taber abrasion
UNI 9428/89 Scratch resistance
EN 12720/97 Resistance to cold liquids (stains)
EN 12721/97 Resistance to moist heat
EN 12722/97 Resistance to dry heat
EN ISO 1520/95 Static drawing
UNI 9240/87 Adhesion of finishes to the substrate
